- Mã sản phẩm: KM-2013WDP
- Giá: Liên hệ
- Tình trạng: còn hàng
- Bảo hành : 24 tháng
- Lượt xem: 1224
- Bảng giá:
Đặc tính kỹ thuật
Model |
KM-2013WDP |
|
Image Sensor |
1/3 inch 1.3 Megapixel progressive scan CMOS |
|
Effective Pixels |
1280 (H) x 960 (V) |
|
Scanning System |
Progressive |
|
Electronic Shutter Speed |
Auto/ Manual, 1/3(s) - 1/30000s |
|
Min. Illumination |
0.1Lux/F1.2 (Color) |
|
S/N Ratio |
More than 50dB |
|
Camera Features |
||
Max. IR LEDs Length |
15 m |
|
Day/Night |
Auto (ICR)/ Color/ B/W |
|
Backlight Compensation |
BLC/ HLC/ DWDR |
|
White Balance |
Auto/ Manual |
|
Gain Control |
Auto/ Manual |
|
Noise Reduction |
3D |
|
Privacy Masking |
Up to 4 areas |
|
Zoom |
3x |
|
Lens |
||
Focal Length |
3.6mm |
|
Max Aperture |
F1.2 |
|
Focus Control |
Manual |
|
Angle of View |
H: 70° |
|
Lens Type |
Fixed lens |
|
Mount Type |
Board-in Type |
|
Pan/ Tilt |
||
Pan/ Tilt Range Pan |
0° ~ 180°; Tilt: 0° ~ 90° |
|
Preset Speed |
100°/s |
|
Preset |
25 |
|
Video |
||
Compression |
H.264/ H.264H/ MJPEG |
|
Resolution |
1.3M (1280 x 960 )/720P (1280 x 720) /D1 (704 x 576/ 704 x 480)/ CIF (352 x 288/ 352 x 240) |
|
Frame Rate |
Main Stream |
1.3M/ 720P(1 ~ 25/30fps) |
Sub Stream |
D1/CIF(1 ~ 25/30fps) |
|
Bit Rate |
H.264: 32K ~ 8192Kbps |
|
Audio |
|
|
Compression |
G.711a/ G.711u/ PCM |
|
Interface |
Built-in Mic |
|
Network |
||
Ethernet |
RJ-45 (10/100Base -T) |
|
Protocol |
IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPoE, DDNS, QoS, UPnP, PNTP, FTP, IP Filter, Bonjour |
|
Wi-Fi |
Wi-Fi (IEEE802.11b/g/n), 50m (open eld) |
|
Compatibility |
ONVIF, CGI |
|
Max. User Access |
20 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone… |
|
General |
||
Power Supply |
12VDC |
|
Power Consumption |
< 5W |
|
Dimensions |
130 x 58.4mm |
|
Weight |
0.25kg |
- Thương hiệu KBVISION của Mỹ.
- Sản xuất tại Đài Loan.
- Bảo hành: 12 tháng.
