Operating indicators
|
|
|
|
1 LED (red/green/orange) |
|
|
Buzzer |
|
Operating keys
|
|
|
|
1 scan key |
|
Communication
|
|
|
|
DB9 PTF connector with external power supply |
|
|
MiniDIN6 F/M connector |
|
|
Ver. 2.0, HID/VCP, USB-A connector |
|
Power
|
|
|
|
6V ± 5% (Keyboard Wedge), 6V (min. 4.5, max. 6.5V) (RS232) |
|
|
Max. 350mA (max typical use), 75mA (standby) |
|
2D Imager Optics
|
|
|
|
Green aiming LED, illumination LEDs |
|
|
CMOS area sensor, 752 x 480 pixels, gray scale |
|
|
60 fps |
|
|
Manual, multiple read, auto-trigger, stand detection |
|
|
Windows Bitmap, JPEG, TIFF |
|
|
1024, 256, 16, 2 |
|
|
4 resolutions (full, 1/2, 1/3, 1/4), 2 ranges (horizontal, vertical) |
|
|
-50 to 0°, 0 to +50° |
|
|
-50 to 0°, 0 to +50° |
|
|
360° |
|
|
104 mm |
|
|
R>16 mm (12-digit 0.15 mm Codabar), R>20 mm (13-digit UPC) |
- 2D Min. Resolution at PCS 0.9
|
QR code: 0.127 mm / 5 mil, DataMatrix: 0.169 mm / 7 mil |
|
|
0.3 |
|
|
Horizontal 40.6º, Vertical 26.4º |
|
|
at Code 39: 65 - 105 mm / 2.56 - 4.13 in (0.127 mm / 5 mil), 45 - 185 mm / 1.77 - 7.28 in (0.254 mm / 10 mil) 50 - 250 / ,1.97 - 9.87 in (0.508/20 mil) at QR Code: 70 - 95 mm / 2.76 - 3.74 in (0.212 mm / 8.4 mil), 35 - 165 / 1.38 - 6.50 in (0.381 / 15 mil) |
|
Supported Symbologies
|
|
|
|
JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/ Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey |
|
|
Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code, POSTNET |
|
|
Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code (mode 2~5), MicroPDF417, Micro QR Code, PDF417, QR code |
|
Durability
|
|
|
|
-20 to 50 °C / -4 to 122 °F |
|
|
-20 to 60 °C / -4 to 140 °F |
|
|
5 - 90% (non-condensing) |
|
|
5 - 90% (non-condensing) |
|
|
Fluorescent 10,000 lx max, Direct sun 100,000 lx max, Incandescent 10,000 lx max |
|
|
1.5 m / 5 ft drop onto concrete surface |
|
|
10 - 100 Hz with 2G for 1 hour |
|
|
IP 42 |
|
Physical
|
|
|
|
56 x 148.6 x 108.1 mm / 2.20 x 5.85 x 4.26 in |
|
|
Ca. 85 g / 3 oz (excl. cable) |
|
|
ABS, Black or White |
|
Regulatory & Safety
|
|
|
|
CE, FCC, VCCI, RoHS, IEC 62471-1, IEC 60825-1 Class 1, IEC 60950-1 |
