| System |
| Main Processor |
Industrial-grade processor |
| Operating System |
Embedded Linux |
| Operating Interface |
Web; Local GUI |
| AI |
| AI by Recorder |
Face detection, face recognition, perimeter protection, and SMD Plus |
| AI by Camera |
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
| Perimeter Protection |
| Perimeter Performance AI by Recorder (Number of Channels) |
2 channels, 10 IVS rules for each channel |
| Perimeter Performance of AI by Camera (Number of Channels) |
8 channels |
| Face Detection |
| Face Attributes |
Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Recorder (Number of Channels) |
1 channel (up to 12 face images/s each channel) |
| Face Detection Performance of AI by Camera (Number of Channels) |
8 channels |
| Face Recognition |
| Face Database Capacity |
Up to 10 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image. |
| Face Recognition Performance of AI by Recorder (Number of Channels) |
8-channel FD (by camera) + FR (by recorder), image stream: 12 face images/s
1-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s |
| Face Recognition Performance of AI by Camera (Number of Channels) |
8 channels |
| SMD Plus |
| SMD Plus by Recorder |
4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera |
8 channels |
| Audio and Video |
| Access Channel |
8 channels |
| Network Bandwidth |
AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing
AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing |
| Resolution |
16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF |
| Decoding Capability |
AI disabled: 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps
AI enabled: 1-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 3-channel 8 MP@30 fps; 4-channel 5 MP@30 fps; 6-channel 4 MP@30 fps; 8-channel 1080p@30 fps |
| Video Output |
1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable. |
| Multi-screen Display |
1st Screen: 1/4/8/9
2nd Screen: 1/4/8/9 |
| Third-party Camera Access |
Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon |
| Compression Standard |
| Video Compression |
Smart H.265+; H.265; Smart H.264+; H.264; MJ |
| Audio Compression |
G.711a; G.711u; PCM; G726 |
| Network |
| Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto registe |
| Mobile Phone Access |
iOS; Android |
| Interoperability |
ONVIF 22.06(Profile T; Profile S; Profile G); CGI; SDK |
| Browser |
Chrome; IE9 and later; Firefox |
| Recording Playback |
| Multi-channel Playback |
Up to 8 channels |
| Record Mode |
General, motion detection; intelligent; alarm |
| Backup Method |
USB device and network |
| Playback Mode |
Instant playback, general playback, event playback, tag playback, smart playback |
| Storage |
| Disk Group |
Yes |
| Alarm |
| General Alarm |
Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm |
| Anomaly Alarm |
Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception |
| Intelligent Alarm |
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat m |
| Alarm Linkage |
Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email |
| Port |
| Audio Input |
1-channel RCA |
| Audio Output |
1-channel RCA |
| Alarm Input |
4 channels |
| Alarm Output |
2 channels |
| HDD Interface |
2 SATA ports, up to 16 TB.The maximum HDD capacity varies with environment temperature. |
| USB |
2 (1 front USB 2.0 port, 1 rear USB 2.0 port) |
| HDMI |
1 |
| VGA |
1 |
| Network Port |
1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| General |
| Power Supply |
12 VDC, 4 A |
| Power Consumption |
<10 W(without HDD) |
| Net Weight |
1.51 kg |
| Dimensions (W × L × H) |
375 mm × 284.3 mm × 53 mm |
| Operating Temperature |
–10 °C to +55 °C (14 °F to +131 °F) |
| Storage Temperature |
–20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity |
10%–93% (RH) |
| Installation |
Rack or desktop |
| Certifications |
FCC: 47 CFR FCC Part15, SubpartB, Class A
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021;
EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014 |
