| System |
| Main Processor |
Industrial-grade embedded processor |
| Operating System |
Embedded Linux |
| Operation Interface |
Web; local GUI |
| AI |
| AI by Camera |
Face detection; face recognition; perimeter protection; SMD Plus |
| AI by Device |
Face detection; face recognition; perimeter protection; SMD Plus |
| Perimeter Protection |
| Perimeter Performance AI by Device(Number of Channels) |
1 |
| Perimeter Performance of AI by Camera (Number of Channels) |
4 |
| Face Detection |
| Face Attributes |
6 attibutes: Gender; age group (6); glasses; expressions (8); mouth mask; beard |
| Face Detection Performance of AI by Device (1080P) (Number of Channels) |
1 (up to 12 face images/second) |
| Face Detection Performance of AI by Camera (Number of Channels) |
5 |
| Face Recognition |
| Face Database Capacity |
Up to 10 face databases with 5,000 images |
| Face Recognition Performance of AI by Device (1080P) (Number of Channels) |
1 (up to 4 face images/second |
| Face Recognition Performance of AI by Camera (Number of Channels) |
5 |
| SMD Plus |
| SMD Plus by Device |
4 |
| SMD Plus by Camera |
6-channel SMD Plus (AI by camera): Detects tripwire and intrustion of human or vehicle; filters false alarms caused by leaves, raindrops and change of brightness away |
| Video |
| Access Channel |
16 channels |
| Network Bandwidth |
AI off: Access: 144 Mbps; Storage: 144 Mbps; Forward: 72 Mbps
AI on: Access: 72 Mbps; Storage: 72 Mbps; Forward: 36Mbps |
| Resolution |
12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1 |
| Decoding Capability |
AI disabled: 1-channel 12MP@30 fps; 1-channel 8MP@30 fps; 2-channel 5MP@30 fps; 3-channel 4MP@30 fps; 6-channel 1080p@30 fps
AI enabled: 1-channel 8MP@30 fps; 1-channel 5MP@30 fps; 2-channel 4MP@30 fps; 4-channel 1080p@30 fps |
| Video Output |
1 × VGA, 1 × HDMI (simultaneous) |
| Multi-screen Display |
1, 4, 8, 9, 16 views |
| Third Party Camera Access |
Onvif |
| Compression |
| Video |
Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Audio |
PCM; G711A; G711U; G726 |
| Network |
| Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); P2P;Auto Registration |
| Mobile Phone Access |
Android; iOS |
| Interoperability |
ONVIF (profile T; profile S; profile G); CGI; SDK |
| Browser |
Chrome; IE9 or later; Firefox |
| Record Playback |
| Multi-channel Playback |
Up to 16 channels |
| Record Mode |
Manual record; alarm recordings; motion detection recordings; scheduled recordings |
| Storage |
Local HDD and network |
| Backup |
USB device |
| Playback Function |
1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
2. Full screen; backup (vide clip/file); partially zom in; audio on/off |
| Alarm |
| General Alarm |
Motion detection; privacy masking; video loss; PIR alarm; IPC alarm |
| Anomaly Alarm |
Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security exception |
| Intelligent Alarm |
Face detection; face recognition; perimeter protection (intrusion and tripwire); IVS; SMD Plus |
| Alarm Linkage |
Recording; snapshot; buzzer; log; preset; email; tour |
| External Port |
| HDD |
1 SATA port, up to 10 TB. The maximum HDD capacity varies with environment temperature |
| USB |
1 × front USB2.0; 1 × back USB2.0 |
| HDMI |
1 (max. resolution: 4K) |
| VGA |
1 |
| Network |
1 × RJ-45, 10/100/1,000 Mbps |
| RCA Input |
1 |
| RCA Output |
1 |
| RCA Output |
1 |
| General Parameter |
| Power Supply |
12 VDC, 1.5 A |
| Power Consumption |
Total output of NVR is ≤ 10 W (without HDD) |
| Weight |
0.81kg |
| Dimensions (W × L × H) |
260 mm × 232.7 mm × 47.6 mm |
| Operating Temperature |
-10°C to +55°C (+14°F to +131°F) |
| Storage Temperature |
0°C to 40°C (32°F to 104°F) |
| Operating Humidity |
10%-93% |
| Storage Humidity |
30%-85% |
| Operating Altitude |
3,000 m (9,842.52 ft) |
| Installation |
Desktop |
| Certifications |
FCC:47 CFR FCC Part15, SubpartB, Class A CE-EMC:EN 55032:2015, Class A; EN IEC 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55024:2010+A1:2015; EN 55035:2017; EN 50130-4:2011+A1:2014
CE-LVD:EN 62368-1:2014+A11:2017 |
