| System |
| Main Processor |
Embedded processor |
| Operating System |
Embedded Linux |
| Operating Interface |
Web; Local GUI |
| Perimeter Protection |
| Perimeter Performance AI by Recorder (Number of Channels) |
Advanced Model: 2 channel, 10 IVS for each channel
General Model: 8 channels, 10 IVS for each channel |
| Face Detection |
| Face Attributes |
Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Recorder (Number of Channels) |
2 channels (up to 12 face images/s) |
| Face Recognition |
| Face Database Capacity |
Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries®ions and state can be added to each face picture |
| Face Recognition Performance of AI by Recorder (Number of Channels) |
2 channels |
| SMD Plus |
| SMD Plus by Recorder |
8 channels: Secondary filtering for human and motor vehicle SMD Plus, reducing false alarms caused by leaves, rain and lighting condition change |
| Audio and Video |
| Analog Camera Input |
8 BNC ports, CVI access by default, supports HDCVI/AHD/TVI/CVBS auto-detect |
| Camera Input |
1. CVI: 4K, 6MP, 5MP, 4MP, 1080p@25/30 fps,720p@50/60 fps, 720p@25/30 fps.
2. TVI: 4K, 5MP, 4MP, 3MP, 1080p@25/30, 720p@25/30fps.
3. AHD: 4K, 5MP, 4MP, 3MP, 1080p@25/30, 720p@25/30fps. |
| IP Camera Input |
Up to 16 channels of IPC access
8 IP channels by default + 8 channels (analog channels are converted to IP channels)
incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps
*After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled. |
| Encoding Capacity |
Main stream: All channel 4K@(1-7 fps); 6MP@ (1-10 fps); 5MP@ (1-12 fps); 4K-N/4 MP/3 MP@ (1-15 fps); 4M-N/1080P/720P/960H/D1/CIF (1fps–25/30fps); Sub stream: 960H@ (1 fps–15 fps); D1/CIF@ (1 fps–
25/30 fps) |
| Dual-stream |
Yes |
| Video Frame Rate |
PAL: 1 fps–25 fps.
NTSC: 1 fps–30 fps |
| Video Bit Rate |
32 Kbps–6144 Kbps Per Channel |
| Audio Sampling |
8 KHz, 16 bit |
| Audio Bit Rate |
64 Kbps |
| Bit Rate Type |
Video stream and composite stream |
| Video Output |
1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and
HDMI is configurable. |
| Multi-screen Display |
When IP extension mode not enabled: 1/4/8/9
When IP extension mode enabled: 1/4/8/9/16 |
| Third-party Camera Access |
Onvif, Panasonic, Sony, Axis, Arecont, Pelco, Canon, Samsung |
| Compression Standard |
| Video Compression |
AI Coding/H.265+/H.265/H.264+/H.264 |
| Audio Compression |
G.711A/G.711u/PCM |
| Network |
| Network Protocol |
HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P |
| Mobile Phone Access |
iPhone, iPad, Android |
| Interoperability |
ONVIF 21.06, CGI |
| Browser |
Chrome, IE9 or above, Firefox |
| Network Mode |
Single-address mode |
| Recording Playback |
| Record Mode |
General, motion detection; intelligent; alarm; POS |
| Recording Playback |
1/4/9 |
| Backup Method |
USB Device/Network |
| Playback Mode |
Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Storage |
| Disk Group |
Yes |
| Alarm |
| General Alarm |
Motion detection, Video Loss, tampering, and local alarm |
| Anomaly Alarm |
No disk, disk error, low space, offline, ip conflict, MAC conflict |
| Intelligent Alarm |
Face detection, face recognition, perimeter protection |
| Alarm Linkage |
Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email |
| Ports |
| Audio Input |
4, RCA (external)
8, BNC (coaxial) |
| Audio Output |
1, RCA |
| Two-way Talk |
Yes (share the same audio input with the first channel) |
| Alarm Input |
8 channels |
| Alarm Output |
3 channels |
| HDD Interface |
2 SATA Ports, up to 16TB, the maximum HDD capacity varies with environment temperature |
| RS-485 |
1 Port, for PTZ Control |
| USB |
2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
| HDMI |
1 |
| VGA |
1 |
| Network Port |
1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| General |
| Power Supply |
DC12V, 4A |
| Power Consumption |
Lower than 10W |
| Net Weight |
1.64 kg (3.62 lb) |
| Gross Weight |
2.82 kg (6.22 lb) |
| Product Dimensions |
1U, 375.0 mm × 289.4 mm × 53.0 mm |
| Operating Temperature |
-10 °C to +55 °C (+14 °F to +131 °F) |
| Operating Humidity |
10%–90% |
| Installation |
Desktop |
| Certifications |
CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
FCC: Part 15 Subpart B |
