| Model |
AC10U |
| Interface |
1xUSB 2.0
3xGE LAN Ports
1xGE WAN Port |
| Button |
1xWiFi On/Off button
1xReset/WPS button |
| Power Supply |
Power Input: 100-240V-50/60Hz
Power Output: DC 12V-2A |
| Dimension |
Package Box: 390x198x70mm（LxWxH)
Device: 220x141.5x49mm（LxWxH) |
| Weight |
Gross Weight: 810g
Net Weight: 350g |
| Antenna |
4x5dBi External Dual Band Antennas |
| LED indicator |
1xWAN, 1xLAN, 1xWi-Fi/WPS, 1xSYS |
| Standard&Protocol |
Wireless Standards:IEEE 802.11ac/n/a 5GHz
IEEE 802.11n/g/b 2.4GHz
Wired Standards:IEEE 802.3, IEEE 802.3u |
| Frequency |
5GHz: Up to 867Mbps
2.4GHz: Up to 300Mbps |
| Transmit Power |
CE:
FCC:<30dBm |
| Wireless Security |
WPA-PSK, WPA2-PSK, WPA/WPA2
Wireless Security: Enable/Disable
WPS Fast Encryption |
| WAN Connection Type |
Dynamic IP/Static IP/PPPoE
Connection Type Auto Detection
Broadband Account and Password Migration |
| Working Mode |
Router/AP/Universal Repeater/WISP |
| Management |
Local Management
Remote Management
Tenda APP |
| Basic Function |
MU-MIMO
SSID Broadcast and Hide
Beamforming
Signal Power Adjustment |
| Virtual Server |
UPnP
DMZ
Port Forwarding |
| DHCP |
DHCP Server and Client
DHCP Client List
DHCP Address Reservation |
| DDNS |
DynDns, NO-IP, Oray.com, 3322.org, 88ip |
| VPN |
PPTP Client
PPTP Server
L2TP Client |
| Firewall |
Forbid UDP Flood Attack
Forbid TCP Flood Attack
Forbid ICMP Flood Attack
Forbid WAN Ping from Internet
PPTP Pass Through
L2TP Pass Through
IPSec Pass Through |
| Features |
Smart Wi-Fi Schedule
Smart Power Saving
Smart LED On/Off |
| Other |
FTP/Samba
Bandwidth Control
MAC Address Filter
IP and MAC Address Binding
IPTV
Black/White List
MAC Clone
Static Routing
System Log
Network Time
Backup/Restore Settings
System Upgrade Online |
| Certification |
CE, FCC, RoHS, BSMI, NCC, EAC, IC |
| Default Settings |
Default Access Address: tendawifi.com or http://192.168.0.1 |
| Package Content |
AC1200 Smart Dual-Band Gigabit WiFi Router
Power Supply
Ethernet Cable
Quick Installation Guide |
| System Requirements |
Microsoft Windows XP, Vista™ or Windows 7, Windows 8/8.1/11 MAC OS, UNIX or Linux |
| Temperature |
Operating Environment:0℃~40℃
Storage Environment:-40℃~70℃ |
| Humidity |
Operating Environment:10%~90% RH non-condensing
Storage Environment:5%~90% RH non-condensing |
| USB Sharing |
Support Samba/FTP Server |
